IBM Asia Pacific Sales Manual
Revised: October 15, 2019.

Ibm Xiv Storage System
Ibm Xiv Installation Guide
Ibm Xiv Storage System User Manual Pdf Download Pc
Ibm Xiv Storage System User Manual 2017 3 Pdf
Ibm Xiv

Implementing the IBM XIV Storage System server with IBM i 37 38 IBM XIV Storage System with the Virtual I/O Server and IBM i 4 Chapter 4. Performance considerations for IBM i with the IBM XIV Storage System For this paper, we tested IBM i client logical unit numbers (LUNs) defined on.
The IBM XIV® Storage System is a revolutionary high-end open disk system designed to support key current and future business require- ments for a highly available information infrastructure. Its design is a grid of standard Intel®/Linux® components, connected in any-to-any.

Statement in IBM XIV Storage System Safety Notices. For example, if a danger statement contains the identifier D004, translations for that danger statement appear in IBM XIV Storage System Safety Notices under statement D004. In addition to these notices, labels might be attached to the product to warn of potential hazards. IBM® XIV® Storage System is high-end disk storage that supports the need for high performance, availability, operational flexibility and security while helping minimize costs and complexity. Built optimized to simplify storage, XIV Storage System is enabling thousands of organizations to. The XIV Grid Storage Platform is designed to guarantee secure, dependable, enterprise-grade data storage and access, straightforward and non-intrusive installation and upgrade and full scalability. IBM DS8800 Manuals & User Guides. User Manuals, Guides and Specifications for your IBM DS8800 Storage. Database contains 1 IBM DS8800 Manuals (available for free online viewing or downloading in PDF): Introduction and planning manual.

Table of contents

Product life cycle dates	Technical description
Abstract	Publications
Highlights	Features
Description	Accessories
Product positioning	Supplies
Models

Product life cycle dates

Type Model	Announced	Available	Marketing Withdrawn	Service Discontinued
2810-114	2011/07/12	2011/09/08	2013/10/25	2020/12/31

Abstract

The IBM 2810 XIV Storage System Gen3 Model 114 for machine types 2810and 2812 is an innovative, high-end, open disk system designed to helpreduce costs, simplify management and speed access to important data.IBM XIV Storage System Model 114 for machine types 2810 and 2812 is nowoffering the 3 Terabyte (TB) Serial-Attached SCSI (SAS) hard disk drivespopulated in the XIV interface and data modules.

IBM XIV Storage System Gen3 with software release 11.1 now includessupport for optional IBM XIV SSD Caching. This new feature is designedto provide a performance boost for Gen3 systems with more cache capacitythan existing DIMM RAM and the ability to serve up to 3x the performancefor OLTP workloads. With SSD caching, Gen3 with software release 11.1further strengthens its ability to provide consistent high performanceand enterprise functionality, along with low total cost of ownership(TCO) and ease of use. The enhancements in this release is intended toenable:

Highlights

IBM XIV Storage Systems Gen3 is designed to provide ahigher-performing option in enterprise-class storage from the IBM XIVStorage System series. XIV Gen3 model 114 offers up to four times theperformance of previous generation systems and includes:

A virtualized grid-based array of storage devices
Up to 180 2 TB Serial Attached SCSI (SAS) hard disk drives
Up to 161 TB of useable capacity in a single frame
Up to 24 ports of 8Gb Fibre Channel host connectivity
Up to 22 ports of 1Gb iSCSI host connectivity
Up to 360 GB of cache
High-performance InfiniBand interconnectivity
Multi-core processors
Advanced software functions:
Ease of management: Ease of management that goes below thesurface, with a virtualized architecture, highly intuitive GUI, andclever implementation of role-based management all add up to create astreamlined user experience, with less administration.
High performance: A high-speed InfiniBand internalinterconnect, load balancing, use of all system resources, innovativecaching, and massive CPU power combine to support high performance.
Enhanced Connectivity: The IBM XIV Gen3 offers improvedhost connectivity with up to twenty-four 8Gbps Fibre Channel ports and upto twenty-two 1Gbps iSCSI host connectivity ports.
Reliability: High reliability and availability throughhardware redundancy, rapid rebuild times, automatic self-healing, andpreemptive, proactive support services.
Improved capacity usage: Efficient capacity utilizationfunctionality, including space-efficient snapshots and advanced thinprovisioning, helps support savings in capacity and cost, and lessadministration requirements.
High-Density Storage: Enterprise-class, high density SASdisk drives create increased physical space efficiencies. Using 2 TBdrives. XIV Gen3 provides 161 TB useable capacity in a single rack. Theability to store so much data in one system using fewer, large capacitydrives, as well as the use of multi-core processors, can help to reducepower and cooling expenses for a more energy-efficient solution.
Innovative Caching: Up to 360 GB of total system cachewith flexible and powerful cache implementation allows the XIV system toleverage large slots for reads while enabling it to manage a smaller slotsize for improved cache management and better performance.
IBM XIV Storage System Gen3 will be upgradeable to an SSD Cachingoption which is planned for the first half of 2012. The SSD cachingoption is being designed to provide up to 6 TB of fast read cache tosupport and up to a 90% reduction in I/O latency for random readworkloads.
Flexible Warranty: Configurations are available in bothone-and three-year warranty options.
Capacity on Demand Configurations: CoD configurations areavailable to provide a method to quickly provision new physical storageand can be ordered at any of the valid partially populated capacities.Up to three CoD modules can be over-provisioned. Contact your salesrepresentative for further details on CoD conditions.

The following tables depict the configurations supported on the IBMXIV Storage System Gen3 Model 114:

2 TB HDD modules

The IBM XIV Storage System Gen3 Model 114 is now able to scale evenhigher in a single rack footprint.

The XIV line of storage products continues to provide the same greatease-of-management and reliability. Now, XIV is able to offer even morecapacity to support high-performance enterprise workloads.

The unique XIV architecture supports the use of high-density driveseven for high-performance enterprise environments. The new support of 3TB SAS drives allows more than 50% greater capacity than the 2 TB drivesand greater storage density per rack, which can help lower per-terabytecosts.

The following tables depict the configurations supported on the IBMXIV Storage System Gen3 with 3 TB SAS drives.

3 TB HDD modules

IBM XIV Storage System Gen3 with software release 11.1 Model 114 nowsupports SSD as read cache.

The availability of SSD caching brings an additional performance boostto IBM XIV Storage System Gen3. With SSD caching, the Gen3 with softwarerelease 11.1 further strengthens its ability to provide consistent highperformance and enterprise functionality for open system storage, alongwith low total cost of ownership (TCO) and ease of use.

Product positioning

Models

Model summary matrix

Model	Processor	Physical Capactiy	Disk Drives	Processor Memory	Host Adapters
114	Intel Grid	540 TB	180	360 GB	15

Customer setup (CSU)

The XIV is not designated as customer setup.

Devices supported

Information on servers, operating systems, host adapters, andconnectivity products supported by the XIV is available at the SSICwebsite:

Model conversions

None.

Feature conversions

Technical description

Physical specifications	Operating environment	Limitations
Hardware requirements	Software requirements

The IBM XIV Storage System series is an innovative, high-end, opendisk system series designed to support business requirements for a highlyavailable information infrastructure. The XIV architecture is a grid ofstandard Intel and Linux components connected in any-to-any topology.This architecture is designed to support enterprise-class reliability,performance, and scalability.

IBM XIV Storage System Gen3 carries on the XIV tradition of providingconsistent, high performance, and high reliability with a low total costof ownership. Several design factors contribute to this achievement:

Self-tuning and self-healing: XIV's unique fullyvirtualized architecture supports high system performance without manualtuning. The system can self-optimize automatically upon changes in thehardware configuration, such as the addition of modules or replacement ofmodules upon failure.
Ease of management: Ease of management that goes below thesurface, with a virtualized architecture, highly intuitive GUI, andclever implementation of role-based management all add up to create astreamlined user experience, with less administration.
High performance: A high-speed InfiniBand internalinterconnect, load balancing, use of all system resources, innovativecaching, and massive CPU power combine to support high performance.
Enhanced Connectivity: The IBM XIV Gen3 offers improvedhost connectivity with up to twenty-four 8Gbps Fibre Channel ports and upto twenty-two 1Gbps iSCSI host connectivity ports.
Reliability: High reliability and availability throughhardware redundancy, rapid rebuild times, automatic self-healing, andpreemptive, proactive support services.
Improved capacity usage: Efficient capacity utilizationfunctionality, including space-efficient snapshots and advanced thinprovisioning, helps support savings in capacity and cost, and lessadministration requirements.
High-Density Storage: Enterprise-class, high density SASdisk drives create increased physical space efficiencies. Using 2 TBdrives. XIV Gen3 provides 161 TB useable capacity in a single rack. Theability to store so much data in one system using fewer, large capacitydrives, as well as the use of multi-core processors, can help to reducepower and cooling expenses for a more energy-efficient solution.
Innovative Caching: Up to 360 GB of total system cachewith flexible and powerful cache implementation allows the XIV system toleverage large slots for reads while enabling it to manage a smaller slotsize for improved cache management and better performance.
IBM XIV Storage System Gen3 will be upgradeable to an SSD Cachingoption which is planned for the first half of 2012. The SSD cachingoption is being designed to provide up to 6 TB of fast read cache tosupport and up to a 90% reduction in I/O latency for random readworkloads.
Flexible Warranty: Configurations are available in bothone-and three-year warranty options.
Capacity on Demand Configurations: CoD configurations areavailable to provide a method to quickly provision new physical storageand can be ordered at any of the valid partially populated capacities.Up to three CoD modules can be over-provisioned. Contact your salesrepresentative for further details on CoD conditions.

The following tables depict the configurations supported on the IBMXIV Storage System Gen3 Model 114:

2 TB HDD modules

The IBM XIV Storage System Gen3 Model 114 is now able to scale evenhigher in a single rack footprint.

The XIV line of storage products continues to provide the same greatease-of-management and reliability. Now, XIV is able to offer even morecapacity to support high-performance enterprise workloads.

The following tables depict the configurations supported on the IBMXIV Storage System Gen3 with 3 TB SAS drives.

3 TB HDD modules

IBM XIV Storage System Gen3 with software release 11.1 Model 114 nowsupports SSD as read cache.

Width: 660 mm (26 in)
Depth: 1200 mm (47.2 in)
Height: 2020 mm (79.5 in)
Weight: 1044.5 kg (2303.1 lb)

To assure installability and serviceability in non-IBMindustry-standard racks, review the installation planning information forany product-specific installation requirements.

Operating environment

IBM XIV Storage System Model 2810-114

Temperature: 10 to 35 degrees C (50 to 95 degrees F)
Relative humidity: 25% to 80%
Wet bulb (caloric value): 23 kcal/hour or Btu
Electrical power:
- 2TB HDD - 6.7 kVA max consumption
- 3TB HDD - 7.0 kVA max consumption
Noise level: 56 dBa

Limitations

Existing drive rules apply:
- Plant install / field install: Plant install only.
- Customer Setup: No.
(#0036) OEM unit indicator
This feature provides an XIV rack and components that do not includeIBM or XIV branding. It is intended for OEM use only.
- This feature is mutually exclusive of feature #0035.
- One of feature #0035 or #0036 must be selected at initial order.
Plant install / field install: Plant install only.
Customer Setup: No.

(#0080) Ruggedized Rack

(No Longer Available as of July 11, 2017)

This feature provides a different method to mount the rack in yourenvironment. It has additional bracing and floor mounting methods tohelp resist damage in earthquake prone environments.

Minimum required: 0
Maximum allowed: 1
Prerequisite:
Corequisites:
Limitations:
Plant install / field install: Both
Customer Setup: No

(#0100) UNIX Host Attachment

(No Longer Available as of July 11, 2017)

This feature indicates a customer preference for UNIX (AIX, HP-UX,Solaris) host attachment.

Minimum required: None.
Maximum allowed: One.
Corequisites: None.
Limitations: None.
Plant install / field install: Both.

(#0102) Windows Host Attachment

(No Longer Available as of July 11, 2017)

This feature indicates a customer preference for Windows hostattachment.

Minimum required: None.
Maximum allowed: One.
Corequisites: None.
Limitations: None.
Plant install / field install: Both.

(#0200) Height / Weight Reduction

This optional feature ensures the maximum shipping weight of themachine does not exceed 1018 kg(2239.5 lb) during the initial shipment. This feature is ordered forinstallations where receiving a full sized assembled storage unit wouldbe impractical. The unit would be delivered fully tested but partiallydisassembled into several easily transported subassemblies. This featurewould allow racks to be safely transported on lower weight capacityelevators. At the installation site, the unit will be assembled andinstalled by IBM technicians. This feature will increase the machineinstallation time and should only be ordered if required when the machinehas 12 modules or more. This feature allows the removal of the topmodules (#12-15), then the top hat of the rack can be taken off to ensurethe height of the machine is reduced by 68 cm (15 in), so themachine is shorter and can fit into doors.

Minimum required: None.
Maximum allowed: 99.
Corequisites: None.
Limitations: This feature is mutually exclusive of feature #0201.
Plant install / field install: Both.

(#0203) RFID Labeling

(No Longer Available as of July 11, 2017)

This feature provides one RFID tag which will be attached to theoutside of the product for potential use with the customer-designatedtracking systems. While discretion has been used in the placement of thetag on the product, this tag is not necessarily designed to beaesthetically pleasing and should not be added to the order. The maximumorder quantity for this feature is one, and this feature is for initialplant order only.

For clients who have a signed IBM Customer Agreement (orequivalent):
- IBM Agreement for XIV Standby Capacity on Demand (U.S., formnumber Z125-8098), and
- IBM Supplement for XIV Standby Capacity on Demand (U.S., formnumber Z125-8097)

Once a client has executed either set of the above agreements, eachsubsequent order for any feature #1149 requires only that the customersigned an additional IBM Supplement for XIV Standby Capacity onDemand.

Minimum required: One.
Maximum allowed: One.
Prerequisites: None.
Corequisites: None.
Limitations: Cannot be ordered with feature #1149 or feature #1150.
Plant install / field install: Plant Install only.

(#1122) 1TB Raw Capacity Per Drive Interface Module

(No Longer Available as of July 11, 2017)

This feature provides an Infiniband-attached XIV interface modulepopulated with a quantity of twelve drives of 1 TB raw capacity perdrive. Interface modules also provide the connectivity to externalhosts.

Minimum required: 3.
Maximum allowed: 9.
Prerequisite: On the initial and MES order, feature #1123 canonly be paired with feature #1122. If the total quantity of feature#1123 (installed and on order) is three, the quantity of feature #1122must be three. If the total quantity of feature #1123 (installed andon order) is more than three, the quantity of feature #1122 must besix. The maximum number of feature #1123 is 9.
Corequisites: None.
Limitations: None.
Plant install / field install: Both.
Customer Setup: No.

(#1125) 2TB Interface Module

(No Longer Available as of July 11, 2017)

This feature provides an Infiniband-attached XIV interface modulepopulated with a quantity of 12 2TB HDDs.

Minimum required: 3
Maximum allowed: 9
Prerequisite: On initial order and MES order, 1126 can only bepaired with 1125;
Corequisites: None
Limitations: None
Plant install / field install: Both
Customer Setup: No

(#1135) 3TB Interface Module

(No Longer Available as of July 11, 2017)

This feature provides an Infiniband-attached XIV interface modulepopulated with a quantity of 12 3TB HDDs.

Minimum required: 3
Maximum allowed: 9
Prerequisite: On initial order and MES order, 1136 can only bepaired with 1135;
Corequisites: None
Limitations: None
Plant install / field install: Both
Customer Setup: No

(#1145) 2TB COD Interface Module

(No Longer Available as of December 5, 2017)

This feature provides the same interface module functionality asfeature #1135 above, but is used to indicate a Capacity on Demand (CoD)order.

Minimum required: 3
Maximum allowed: 9
Prerequisite: None
Corequisites: Must be ordered with 1145
Limitations: Sum of 1145 and 1146 cannot exceed quantity of feature1149 plus three
Plant install / field install: Both
Customer Setup: No

(#1147) 3TB CoD Interface Module

(No Longer Available as of December 5, 2017)

This feature has the same description as feature #1137 above, but isused to indicate a Capacity on Demand (CoD) order.

Minimum required: 3
Maximum allowed: 9
Prerequisite: None
Corequisites: Must be ordered with 1147
Limitations: Sum of 1147 and 1148 cannot exceed 1150 plus 3
Plant install / field install: Both
Customer Setup: No

(#1149) 2TB HDD CoD Activation

(No Longer Available as of July 11, 2017)

This feature is used to increment the licensed available capacity in a2 TB module Capacity on Demand machine. It provides 10.7 TB of useablecapacity in fifteen module 2TB COD configurations. Activation useablecapacity varies with the number of modules in the configuration. Aminimum of three activations are required for an initial 6 module 2 TBCoD order. The quantity of 1149 must be no more than 3 less the totalquantity of 1145 and 1146. For example, 9 module physical configurationsmust have 6 activations. 14 module physical configurations must have 11activations. This rule applies to all valid partially populatedconfigurations.

Minimum required: 3
Maximum allowed: 15
Prerequisite: Must have 1147 or 1148
Corequisites: None
Limitations: Must not be more than three less the total of 1147 and1148
Plant install / field install: Both
Customer Setup: No

(#1155) IBM XIV SSD Caching

(No Longer Available as of July 11, 2017)

This feature provides a performance boost for Gen3 systems, offeringmore cache capacity than existing DIMM RAM and the ability to serve up to3x the performance for OLTP workloads.

Minimum required: None.
Maximum allowed: 99.
Corequisites: None.
Limitations: None.
Plant install / field install: Both.

(#9101) Modem

(No Longer Available as of July 11, 2017)

This feature provides a modem that is installed in the XIV StorageSystem rack. The modem is used for remote support activities and is arequired feature where available. The modem is available in thefollowing countries:

(#98xx) Power line cords

(No Longer Available as of July 11, 2017)

In addition to selecting a single-phase or three-phase ATS feature,country and amperage specific line cords must be selected. Refer to thetable below for the number of cords that ship per feature number. TheIBM XIV Installation and Planning Guide has additional information onpower.

All #981x features require the ATS feature #9890.
Feature #9820 require the ATS feature #9891.
Feature #9822 requires the ATS feature #9892.
Feature #9824 requires the ATS feature #9894.

Plant install / field install: Both.

Ibm Xiv Installation Guide

(#989x) Power options

(No Longer Available as of July 11, 2017)

One of the following Automatic Transfer Switches (ATS) must beselected based upon your GEO and site requirements. The IBM XIVInstallation and Planning Guide has additional information on power.

Feature #9890 requires quantity one of line cord feature #9807 or any#981x line cord feature.
Feature #9891 requires quantity one of line cord feature #9820.
Feature #9892 requires quantity one of line cord feature #9822.
Feature #9894 requires quantity one of either line cord feature#9824.

Limitations:

Product life cycle dates

Abstract

Highlights

Description

Product positioning

Models

Model summary matrix

Customer setup (CSU)

Devices supported

Model conversions

Feature conversions

Technical description

Operating environment

Limitations

Publications

Features

Features - No charge

Features - Chargeable

Feature descriptions

(#0018) AAS SW order indicator

(#0035) Retail unit indicator

(#0036) OEM unit indicator

(#0080) Ruggedized Rack

(#0100) UNIX Host Attachment

(#0102) Windows Host Attachment

(#0200) Height / Weight Reduction

(#0203) RFID Labeling

(#1122) 1TB Raw Capacity Per Drive Interface Module

(#1125) 2TB Interface Module

(#1135) 3TB Interface Module

(#1145) 2TB COD Interface Module

(#1147) 3TB CoD Interface Module

(#1149) 2TB HDD CoD Activation

(#1155) IBM XIV SSD Caching

(#9101) Modem

(#98xx) Power line cords

Ibm Xiv Installation Guide

(#989x) Power options

Accessories

Customer replacement parts

Supplies

Supplemental media

Ibm Xiv Storage System User Manual Pdf Download Pc

Trademarks

Ibm Xiv Storage System User Manual 2017 3 Pdf

Terms of use

Ibm Xiv
